TL-WN781ND has one detachable antenna that can be rotated and adjusted in different directions to fit various operation environments. And also, the antenna can be replaced with diverse indoor antenna or directional antenna to show wider wireless coverage. Compared to standard PCI network cards, TL-WN781ND offers increased bandwidth, reliability and functionality. It delivers up to 150Mbps wireless transmission rate, allowing you to have a joyful surfing experience, including sharing files, watching streaming media.
Features
- Stable Wireless Connection Ensure Your Surfing Experience
- Great Flexibility with Detachable Antenna
HARDWARE FEATURES
Interface
- PCI Express
Dimensions ( W x D x H )
- 4.8 x 3.1 x 0.8in. (120.8 x 78.5 x 21.5mm)
Antenna Type
- Detachable Omni Directional (RP-SMA)
Antenna Gain
- 2dBi
WIRELESS FEATURES
Wireless Standards
- IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency
- 2.400-2.4835GHz
Signal Rate
- 11n: Up to 150Mbps(dynamic)
- 11g: Up to 54Mbps(dynamic)
- 11b: Up to 11Mbps(dynamic)
Reception Sensitivity
- 130M: -68dBm@10% PER
- 108M: -68dBm@10% PER
- 54M: -68dBm@10% PER
- 11M: -85dBm@8% PER
- 6M: -88dBm@10% PER
- 1M: -90dBm@8% PER
Transmit Power
- <20dBm(EIRP)
Wireless Modes
- Ad-Hoc / Infrastructure mode
Wireless Security
- Support 64/128 bit WEP, WPA-PSK/WPA2-PSK
Modulation Technology
- DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
OTHERS
Certification
- CE, FCC, RoHS
Package Contents
- Wireless Adapter
- Detachable Omni directional antenna
- Resource CD
- Quick Installation Guide
System Requirements
- Windows XP/Vista/7/8/8.1/10(32/64bits)
Environment
- Operating Temperature: 0℃~40℃ (32℉~104℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
