As a Wireless N Nano USB adapter, TL-WN725N allows users to connect a desktop or notebook computer to a wireless network at speed of up to 150Mbps, which is ideal for smooth video streaming, voice streaming and online gaming. TL-WN725N is designed to be as convenient as possible. With its miniature size and sleek design, users can connect the nano adapter to any USB port and leave it there, no matter when they are traveling or at home.
Features:
Speed
- Fast Wi-Fi: Great for surfing, emailing and posting social
media
Easy of use
- Backward Compatibility: Supports routers utilizing
802.11b and 802.11g Wi-Fi standards
Design
- Sleek miniature design: The adapter is so small
that once plugged in, can be left in a computer’s USB port
Security
- Active Defense: WPA/WPA2 encryption provides your
Wi-Fi network with advanced protection against security threats
Hardware Features:
Interface
- USB 2.0
LED
- Status
Weight
- 0.07 ounces / 2.1 grams (Without packaging)
Dimensions ( W x D x H )
- 0.73×0.59×0.28in.(18.6x15x7.1mm)
Antenna Type
- Internal antenna
Wireless Features:
Wireless Standards
- IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Frequency
- 2.400-2.4835GHz
Signal Rate
- 11b: Up to 11Mbps (dynamic)
- 11g: Up to 54Mbps (dynamic)
- 11n: Up to 150Mbps (dynamic)
Reception Sensitivity:
- 130M: -68dBm@10% PER
- 108M: -68dBm@10% PER
- 54M: -68dBm@10% PER
- 11M: -85dBm@8% PER
- 6M: -88dBm@10% PER
- 1M: -90dBm@8% PER
Transmit Power
- <20dBm
Wireless Modes
- Ad-Hoc / Infrastructure mode
Wireless Security
- Supports 64/128 WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES), supports IEEE 802.1X
Modulation Technology
- DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Antenna
- -1.45dBi
Others:
Certification
- CE
- FCC
- IC
- RoHS
Package Contents
- 150Mbps wireless N Nano USB adapter TL-WN725N
- Resource CD
- Quick Installation Guide
System Requirements
- Windows 11/10/8.1/8/7/XP,
- Mac OS 10.15 and earlier,
- Linux
Environment
- Operating Temperature: 0℃~40℃ (32℉~104℉)
- Storage Temperature: -40℃~70℃ (-40℉~158℉)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
