The DGS-F3000 Series Layer 2 Gigabit Outdoor Smart Managed Switches are  equipped  with  4 or 8 100/1000BASE-T PoE  ports & 2 or  4 SFP ports respectively.  These switches  feature a robust  design making  them ideal for deployment in Outdoor surveillance , capable of withstanding  the harshest  environment.  The  DGS-F3000  Series furthermore integrates advanced management and security functions to provide a complete solution.

High Redundancy and Reliability

• The DGS-F3000 Series support ERPS <50 ms quick failover recovery for ring topologies that ensures minimal downtime and avoids any loss of data in mission-critical deployment environments. Meanwhile, the dual power input allows for a redundant power supply to make sure the network continues to operate in the event of a primary power supply failure.

Easy Troubleshooting

The DGS-F3000 Series features loopback detection and cable diagnostics to help network administrators and and solve network problems quickly and easily. Loopback detection is used to detect loops created by a specific port and automatically shuts down the affected port. Cable diagnostics helps network administrators quickly examine the quality of the copper cables, recognize the cable type, and detect cable errors.

Durable Design

• The DGS-F3000 Series switches are housed in a highly resistant IP30-rated metal casing to protect the switches from harsh environmental conditions. The high electromagnetic compatibility (EMC) protects the DGS-F3000 Series from unwanted effects when operating in environments with strong electromagnetic interference. Meanwhile, the fanless design extends the life of DGS-F3000 Series while also being able to operate in a wider temperature range of up to 70 °C For increased flexibility, the DGS-F3000 Series can also be mounted on a DIN rail or wall mounted.

Power over Ethernet Support

•  DGS-F3000  series  switches  are  PoE-ready  switches (PoE  models  only)  &  can  provide  total  PoE  budget  up  to 60W  on  DGS-F3004P-2S  Comes with power supply (EDR-120-48) &  120W  on  DGS-F3008P-2S  Comes with power supply (EDR-120-48) , capable  of  supplying  up  to  30  W  of  power  per  port  to connected  PoE-enabled  devices.  This  effectively  reduces deployment  times,  reduces  cable  clutter,  and  eliminates the  need  for  dedicated  power  supplies  to  allow  PoE- devices to be installed in remote locations.

Advanced Features

• The DGS-F3000 Series is equipped with advanced security features such as Static MAC, Storm Control, and IGMP Snooping. Static MAC allows users to create a MAC whitelist for specific ports, helping administrators limit network access to authorized devices only. Storm Control monitors broadcast, multicast, or unknown unicast traffic and will start blocking or discarding packets which could flood the network when the defined threshold is exceeded. IGMP Snooping can reduce the load of L3 multicast routers and save bandwidth in network throughput.

Technical Specifications:

General

Interface

• 8 x 10/100/1000Base-T PoE / PoE+ Ports
• 2 x 1000Base-X SFP Ports

Other Interfaces

• 1 x RS-232 Console Port (RJ-45)
• 2 relay outputs with current carrying capacity of 1A @ 24 VDC

Media Interface Exchange

• Auto MDI/MDIX adjustment for all twisted-pair ports

Other Port standards & Functions

• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)
• IEEE 802.3az compliance
• Auto-negotiation
• IEEE 802.3x Flow Control
• IEEE 802.3z

Duplex Mode

• Full-duplex for 1000 Mbps
• Full/Half-duplex for 10/100 Mbps

Performance:

Switching Capacity

• 20Gbps

MAC Address Table

• 16K

Transmission Method

• Store-and-forward

Packet Puffer Size

• 1.5MB

Physical / Environmental:

Diagnostic LED

• PWR1
• PWR2
• Alarm
• SYS
• LINK/ACT
• PoE Status

Weight

• 1Kg

Dimensions

• 163 x 46.5 x 10 mm

Operating Temperature

• -40°C~85°C (-40°F~185°F)

Ambient Relative Humidity

• 5%~95%, 55°C (Non-condensing)

Housing

• IP40-rated metal casing

Installation

• DIN rail / wall mountable

Power Requirements

Power

• 48-56V DC Redundant Inputs with power supply included

Input Current

• 5.0A @ 51VDC

Reverse Polarity Protection

• Yes

Software Features:

Protocol Support

• IPv4 / IPv6
• IGMP
• v1/v2/v3 snooping
• MLD v1/v2 snooping
• DHCP Relay
• GARP, GVRP, NTP, SNTP
• 802.1x
• EAP
• SNMP v1/v2/v3
• RMON
• TFTP
• ICMP
• Telnet
• Syslog
• LLDP
• LACP
• Pingv6

VLAN

• 802.1Q VLAN (512 Active VLAN)
• Port Based VLAN
• MAC Based VLAN

QoS

• 802.1p
• 4 Priority Queues
• Queue Handling: Strict, Weighted Round Robin

Security

• 802.1x
• Layer 2 & Layer 3 ACL

Standards / Certifications / Compliance:

Safety

• UL 60950-1 2nd Ed. /CSA C22.2 No.60950-1-07 2nd Ed. / EN 60950-1 / CB

EMC

• FCC Part 15
• Subpart B
• Class A
• EN 55032
• EN 55024
• EN 61000-3-2
• EN 61000-3-3
• EN 61000-6-2
• EN 61000-6-4

EMS

• IEC 61000-4-2 ESD
• IEC 61000-4-3 RS
• IEC 61000-4-4 EFT
• IEC 61000-4-5 Surge
• IEC 61000-4-6 CS
• IEC 61000-4-8 PFMF
• IEC 61000-4-11 DIP

Shock

• MIL-STD-810G Method 516.5

Vibration

• MIL-STD-810F Method 514.5 C-1 & C-2

Freefall

• MIL-STD-810F Method 516.5

Environmental

• ROHS II

MTBF

• 175200 Hrs.
