DAP-X2850 provides businesses of all sized with unbeatable speeds, significantly increased capacity and interference-free coverage, combined with centralised management by Nuclias Connect.
Features
- Easy to manage with D-Link’s free centralised management software-
based solution, Nuclias Connect - Wi-Fi 6 delivers greater network efficiency and lower latency, with nearly four times the capacity of previous Wi-Fi standards
- MU-MIMO slices through congestion, reducing wait time for all users
- Superior throughput with dual-band Wi-Fi offers high transfer speeds
- Coverage is shared more efficiently over more users with Airtime Fairness
- Band Steering intelligently manages users, pushing them onto the
higher radio frequency when possible - Two LAN ports (2.5G and 1G) offer expansive backhaul to your wired network, eliminating bottlenecks at the AP
- Support for Power of Ethernet 802.3at means fewer wires, for cleaner and easier deployment
- Stay secure with the latest WPA3™ Personal & Enterprise wireless
encryption - Supports multiple AP modes to ensure performance optimization based on your network’s needs
- MAC Address Filtering and WLAN Partitioning ensure ultimate control of your network’s access
- Captive Portal with industry-standard authentication for enhanced access management
- Works as a standalone AP or as part of a centralised, scalable multi-device deployment
Technical Specifications:
General
Device Interfaces
- 1 x RJ45 console port, 1 x 2.5 Gbps Ethernet
- LAN (PoE), 1 x 10/100/1000 Mbps Ethernet
- LAN, factory reset, power input
LEDs
- Power/Status
Antennas
- 4 x internal
Antenna Gain
- 3.5 dBi (2.4 GHz), 5.5 dBi (5 GHz)
Data Signal Rate
- 2.4 GHz – Up to 1147 Mbps (1024QAM)
- 5 GHz – Up to 2402 Mbps (1024QAM)
Functionality:
- Standards
- IEEE 802.11a/b/g/n/ac/ax
- IEEE 802.3u/ab,
- IEEE 802.3az Energy-Efficient Ethernet (EEE)
- IEEE 802.3at PoE
Operating Frequency
- 2.4 – 2.483 GHz, 5.15 – 5.35 GHz, 5.47 – 5.85 GHz
Security Protocol
- WPA/WPA2/WPA3™ Personal/Enterprise,
- WEP 64/128-bit, SSID broadcast disable
- MAC address access control, internal RADIUS server
Power/Status
- Software
Network Management
- Telnet
- SSH
- Web (HTTP)
- Secure Socket Layer (SSL)
- Traffic control
- D-Link Nuclias Connect
Physical:
Power Supply
- Connect 12 V / 2.5 A (optional power adapter not included)
- IEEE 802.3at PoE
Max. Power Consumption
- 19.44 W
MTBF
- > 30,000 hours
Operating Temperature
- 0 ˚C to 40 ˚C
Storage Temperature
- -20˚C to 65 ˚C
Operating Humidity
- 10% to 90%
- LAN LAN Power
- Storage Humidity
- 5% to 95% (PoE) Connector
Weight
- 763.8 g
Dimensions
- 212.4 x 212.4 x 46.7 mm
Certifications
- CE
- FCC
